Javadoc comprehensive guide

A short description and two different block tags, standalone and inline:

• Standalone tags appear after the description, with the tag as the first word in a line, e.g., the @author tag
• Inline tags may appear anywhere and are surrounded with curly brackets, e.g., the @link tag in the description

Private fields won’t have Javadoc generated for them unless -private option is explicitly passed to the javadoc command. We’ll learn about javadoc command later.

Java Software use @version for the SCCS version. The consensus seems to be the following:

• %I% gets incremented each time you edit and delget a file
  • When you create a file, %I% is set to 1.1. When you edit and delget it, it increments to 1.2.
• %G% is the date mm/dd/yy
  • Some developers omit the date %G% (and have been doing so) if they find it too confusing – for example, 3/4/96, which %G% would produce for March 4th, would be interpreted by those outside the United States to mean the 3rd of April! 🤨

/**
 * Example output version
 *
 * @version 1.39, 02/28/97
 */

Assume the classes are all in the src folder in the project directory:

javadoc -d doc src\*

This will generate documentation in a directory called doc, as specified with the –d flag. If multiple packages or files exist, we’d need to provide all of them.

The Javadoc command line tool is very powerful, but has some complexity attached to it.

<build>
    <plugins>
        <plugin>
            <groupId>org.apache.maven.plugins</groupId>
            <artifactId>maven-javadoc-plugin</artifactId>
            <version>3.6.2</version>
            <configuration>
                <source>1.8</source>
                <target>1.8</target>
            </configuration>
            <tags>
            ...
            </tags>
        </plugin>
    </plugins>
</build>

In the base directory of the project, run the command to generate our Javadocs to a directory in target\site:

mvn javadoc:javadoc

The Maven plugin is very powerful, and facilitates complex document generation seamlessly.

The first sentence of each doc comment should be a summary sentence, containing a concise but complete description of the API item. This means the first sentence of each member, class, interface or package description.

/**
* Class constructor.
*/
foo() {
...

/**
* Class constructor specifying number of objects to create.
*/
foo(int n) {
...

Write the description to be implementation-independent, but specifying such dependencies where necessary. This helps engineers write code to be “write once, run anywhere.”

• Define clearly what is required and what is allowed to vary across platforms/implementations.
  • The use of “On Windows” at the beginning of the sentence makes it clear up front that this is an implementation note.
• Where appropriate, mention what the specification leaves unspecified or allows to vary among implementations.
• Ideally, make it complete enough for conforming implementors.
  • Realistically, include enough description so that someone reading the source code can write a substantial suite of conformance tests.
  • Basically, the spec should be complete, including boundary conditions, parameter ranges and corner cases.

You can avoid re-typing doc comments by being aware of how the Javadoc tool duplicates (inherits) comments for methods that override or implement other methods. This occurs in three cases:

• When a method in a class overrides a method in a superclass
• When a method in an interface overrides a method in a superinterface
• When a method in a class implements a method in an interface

• Java keywords
• package names
• class names
• method names
• interface names
• field names
• argument names
• code examples

A method implements an operation, so it usually starts with a verb phrase:

✔️ Gets the label of this button. (preferred)

❌ This method gets the label of this button.

These API often describe things rather than actions or behaviors:

✔️ A button label. (preferred)

❌ This field is a button label. (avoid)

For example, the description of the getToolkit method should read as follows:

✔️ Gets the toolkit for this component. (preferred)

❌ Gets the toolkit for the component. (avoid)

• The best API names are “self-documenting”, meaning they tell you basically what the API does.
  • If the doc comment merely repeats the API name in sentence form, it is not providing more information.

/**
 * ❌ Sets the tool tip text.
 */
public void setToolTipText(String text) {
...

The ideal comment goes beyond those words and should always reward you with some bit of information that was not immediately obvious from the API name.

/**
* ✔️ Registers the text to display in a tool tip. The text
* displays when the cursor lingers over the component.
*/
public void setToolTipText(String text) {
...

Prefer:

• “also known as” to “aka”
• “that is” or “to be specific” to “i.e.”
• “for example” to “e.g.”
• “in other words” or “namely” to “viz.”

Be aware that the word “field” has two meanings:

• static field, which is another term for “class variable”
• text field, as in the TextField class. Note that this kind of field might be restricted to holding dates, numbers or any text. Alternate names might be “date field” or “number field”, as appropriate.

Include tags in the following order:

• @author (classes and interfaces only, required)
• @version (classes and interfaces only, required)
• @param (methods and constructors only)
• @return (methods only)
• @exception (@throws is a synonym added in Javadoc 1.2)
• @see
• @since
• @serial (or @serialField or @serialData)
• @deprecated

• Multiple @author tags should be listed in chronological order, with the creator of the class listed at the top.
• Multiple @param tags should be listed in argument-declaration order. This makes it easier to visually match the list to the declaration.
• Multiple @throws tags (also known as @exception) should be listed alphabetically by the exception names.
• Multiple @see tags should be ordered as follows, which is roughly the same order as their arguments are searched for by javadoc, basically from nearest to farthest access, from least-qualified to fully-qualified, The following list shows this progression.

@see #field
@see #Constructor(Type, Type...)
@see #Constructor(Type id, Type id...)
@see #method(Type, Type,...)
@see #method(Type id, Type, id...)
@see Class
@see Class#field
@see Class#Constructor(Type, Type...)
@see Class#Constructor(Type id, Type id)
@see Class#method(Type, Type,...)
@see Class#method(Type id, Type id,...)
@see package.Class
@see package.Class#field
@see package.Class#Constructor(Type, Type...)
@see package.Class#Constructor(Type id, Type id)
@see package.Class#method(Type, Type,...)
@see package.Class#method(Type id, Type, id)
@see package

• An @param tag is “required” (by convention) for every parameter, even when the description is obvious.
• The @return tag is required for every method that returns something other than void, even if it is redundant with the method description. (Whenever possible, find something non-redundant (ideally, more specific) to use for the tag comment.).

These principles expedite automated searches and automated processing. Frequently, too, the effort to avoid redundancy pays off in extra clarity.
